E10G30-F2 Dual-port 10GbE SFP+ add-in card for Synology systems   High-performance connectivity upgrade Flexible SFP+ options Support for short-range and long-range transceivers as well as DAC options enables flexible connectivity choices. CPU offloading and load balancing Support for CPU offloading and load balancing technologies enables optimal system performance. Specifications: < /p>CompatibilityGeneral Host Bus Interface PCIe 3.0 x8  Bracket Height Low Profile and Full Height  Size (Height x Width x Depth) 69 mm x 168 mm x 17.3 mm  Operating Temperature 0°C to 40°C (32°F to 104°F)  Storage Temperature -20°C to 60°C (-5°F to 140°F)  Relative Humidity 5% to 95% RHNetwork IEEE Specification Compliance

• IEEE 802.3ad Link Aggregation
• IEEE 802.3ae 10Gbps Ethernet

  Data Transfer Rates 10 Gbps  Supported Features

• TCP Segmentation Offload (TSO)
• Receive Side Scaling (RSS)
• Generic Segmentation Offload (GSO)
• 1.5 - 9 KB Jumbo Frame
• TCP/UDP Checksum Offload
• Transmit side scaling (TSS)
• SR-IOV
• Large receive offload (LRO)

Applied Models

• FS series: FS3400
• H D series: HD6500
• S A series: SA6400, SA3410, SA3400, SA3200D
• 23 series: RS2423RP+, DS1823xs+
• 22 series: RS822RP+, DS3622xs+, DS2422+
• 21 series: RS4021xs+, RS3621xs+, RS3621RPxs, RS2421RP+, RS2421+, RS1221RP+, RS1221+, DS1821+, DS1621xs+, DS1621+
• 20 series: RS820RP+
• 19 series: RS1619xs+, DS2419+, DS1819+
• 18 series: RS3618xs, RS2818RP+, RS2418RP+, RS2418+
• 17 series: RS4017xs+, RS3617xs+, RS3617RPxs, DS3617xs
